Delivering industry-leading performance and efficiency, eGen Power® e-Axles feature a compact design to free up space for critical EV equipment including battery packs, offering up new packaging opportunities. The e-Axles are also power agnostic, compatible with battery electric, fuel cell electric and range extending hybrid powertrains.
Regenerative Braking
Integrated Oil Cooler + Oil Pump
Drum or Optional Air Disc Brakes
Modular Design
e-Axles for Commercial Vehicles
An Electric Propulsion Solution for Midi-Buses
The eGen Power® 85S was specifically developed to address the needs of midi bus and small truck applications requiring a lower 8.5T gross axle weight rating (GAWR), with a narrower track width, smaller wheel/tire combinations and new stamped axle housing, as compared to other eGen Power® models.
Electric Power for Medium- and Heavy-Duty Trucks
Built for Heavy-Duty Trucks
The first variant introduced to Allison’s family of fully electric axles, eGen Power® 100D is one of the most powerful fully integrated e-Axle systems in the world. It was specifically developed for heavy-duty trucks, such as 4x2 and 6x2 tractors.
Highly Engineered and Fully Integrated
This 10.4 tonne gross axle weight rated e-Axle features two electric motors, collectively capable of generating greater than 450 kilowatts of continuous power, with peak power of 650 kilowatts. It integrates a two-speed gearbox into the central housing, optimizing for high gradeability and efficient top speed cruise.
eGen Power® 130D
A variant of the 100D, the eGen Power® 130D is specifically designed for European and Asia Pacific markets, where many commercial vehicles require a heavier 13 tonne gross axle weight rating. The 130D maintains the same core components, performance and differentiated value as eGen Power 100D but with an increased axle weight rating.
